Industrial CNC Wood Turning Lathe Machine is a widely demanded device designed for the efficient and precise turning of wooden workpieces. It combines the functionality of a traditional wood lathe with the modern capabilities of CNC technology. The machine allows for automated and programmable turning operations, such as profiling, shaping, and cutting of wood materials. The Industrial CNC Wood Turning Lathe Machine is equipped with a strong structure, a powerful spindle, and a user- friendly interface for programming and operation. It offers high accuracy, versatility and repeatability in the production of several turned wood components such as table legs, balusters, and decorative spindles.
Specification
Working Job Size (Max.) |
Dia 300 mm x 1500 mm |
Working Job Size (Min.) |
Dia 20 mm x 200 mm |
Repositioning Accuracy |
-/+0.05 mm |
X-Y Movement |
Taiwan Rack & Pinion Transmission |
Z Movement |
German Rolling Ball Screw |
Working Voltage |
3 / 380 V / 50 Hz |
Motor Power |
4KW (Variable Speed 0-3500 RPM) |
Spindle Power |
2.2 KW AIR Cooled (0-18000 RPM) |
Working Speed |
4000 mm/min |
Drive Motor |
Stepper |
Command |
G Code (.mmg, .tap, .plt) |
Computer Interface |
USB |
Controls |
NK 105 |
Collet Size |
6mm, 8 mm, 12 mm |
Computer Interface |
Turning/ cylindrical surface carving/ Flat surface carving |
